Falcon™ 4-CLHS Series Series Overview  5
Series Overview
Description
The Falcon4-CLHS series provides affordable easy to use digital cameras specifically engineered for
industrial imaging applications, starting with the industries’ latest leading sensors such as the E2V
Lince 11M series of global shutter high frame rate CMOS sensors. Cameras will be available in a
number of models implementing different sensors, image resolutions and feature sets.
Falcon4-CLHS supports the Teledyne DALSA Trigger-to-Image-Reliability framework to dependably
capture and transfer images from the camera to the host PC.
Falcon4-CLHS Overview
 CLHS 10 Gbps interface per lane
 Supports a power supply input of 10 to 30 Vdc
 Supports the CLHS device discovery methodology providing plug and play capability
 Implements GenICam and associated GenCP compatible with Teledyne DALSA or third party
CLHS frame grabbers
 Acquisitions in 8 or 10-bit
 Optimized, rugged design with a wider operating temperature
 Available in multiple models of different resolutions and maximum frame rates
 Visual camera multicolor status LED on back plate
 Uses one CX4 cable connection
 Flexible general-purpose Counter and Timer functions available for internal and external
controls
 Defective Pixel replacement & Flat Field correction available
 Lens Shading Correction maps for lens vignetting
 Horizontal and Vertical Binning
 Application development with the freely available Sapera™ LT software libraries
 Native Teledyne DALSA Trigger-to-Image Reliability design framework
 Refer to the Operation Reference and Technical Specifications section of the manual for full
details
 Compliant with Camera Link HS (CLHS) specification version 1.0 (X-Protocol)
(visit http://www.visiononline.org/vision-standards.cfm for details on industry standards)
