Dalsa Falcon 4-CLHS Series User Manual

Falcon™ 4-CLHS Series Technical Specifications  95
Pinout Details for FA-HM00-M4485
Pin Number Signal Direction Definition
1 PWR-GND — Camera Power – Ground
2 PWR-VCC — Camera Power – DC +10 to +30 Volts
3 GPI-Common — General Input/Output Common Ground
4 GPO-Power — General Output Common Power
5 GPI 1 In General External Input 1
6 GPO 1 Out General External Output 1
7 GPI 2 In General External Input 2
8 GPO 2 Out General External Output 2
9 GPO 3 Out General External Output 3 / Fast Switching Output
10 Reserved Do not use.
Pinout Details for FA-HM10-M4485, FA-HM11-M4405,
FA-HM10-M8205
Pin Number Signal Direction Definition
1 PWR-GND — Camera Power – Ground
2 PWR-VCC — Camera Power – DC +10 to +30 Volts
3 GPI-Common — General Input/Output Common Ground
4 GPO-Power — General Output Common Power
5 GPI 1 In General External Input 1
6 GPO 1 Out General External Output 1 / Fast Switching Output
7 GPI 2 In General External Input 2
8 GPO 2 Out General External Output 2 / Fast Switching Output
9 GPO 3 Out General External Output 3 / Fast Switching Output
10 GPO 4 Out General External Output 4 / Fast Switching Output
Camera DC Power Characteristics
DC Operating Characteristics
Input Voltage +10 Volts minimum
Input Power Consumption @ +12 Volt Supply 10.02 Watts typical*
Input Power Consumption @ +24 Volt Supply 9.6 Watts typical*
* M4400 and M4480 models. Values for M8200 to be confirmed later.
Absolute Maximum DC Power Supply Range before Possible Device Failure
Input Voltage –50 Volt DC +50 Volts DC

Dalsa Falcon 4-CLHS Series Specifications

General

Brand	Dalsa
Model	Falcon 4-CLHS Series
Category	Digital Camera
Language	English
