Dalsa Falcon 4-CLHS Series User Manual

10  Falcon4-CLHS Specifications Falcon™ 4-CLHS Series
Mechanical Interface
Camera (H x W x L)
see Mechanical Specifications
59 mm x 59 mm x 74.5 mm (M4480, M4400)
59 mm x 59 mm x 74.93 mm (M8200)
Mass Small Case: ~ 317g
CX4 Connector Type Camera Link HS
Power connector Camera power via the power pins on the 10-pin I/O connector
Electrical Interface
Input Voltage +24 V nominal (+10 to +30 Volts DC maximum range)
Power Dissipation (typical)
<13 W @ 24 Vdc (M4480, M4400)
<15 W @ 24 Vdc (M8200)
Environmental Conditions
Operating Temperature
(at camera front plate)
All Models: -20°C to +50°C (-4°F to +122°F). Any metallic camera mounting provides
heat sinking, thereby reducing the internal temperature
Operating Relative Humidity 5% to 90% non-condensing
Storage -40°C to +80°C (-4°F to +176°F) temperature at 20% to 80% non-condensing
relative humidity
Conformity GenIcam compliant
CE, FCC, RoHS, KC
EU RoHS2, EU REACH, China RoHS2
IP Rating IEC60529 IP40
(Protected against foreign object of 1 mm diameter, no protection against water.)
Sensor Cosmetic Specifications
After Factory Calibration and/or Corrections are applied (if applicable — dependent on sensor)
Blemish
Specifications
Maximum Number
of Defects
Blemish Description
Hot/Dead Pixel defects Typical 0.0025%
Max 0.005%
Any pixel that deviates by ±15% from the average of
neighboring pixels at 80% saturation including pixel stuck at 0
and maximum saturated value.
Spot defects none
Grouping of more than 5 pixel defects within a sub-area of 3x3
pixels, to a maximum spot size of 5x5 pixels.
Clusters defects none Grouping of more than 5 single pixel defects in a 3x3 kernel.
Column defects none
Vertical grouping of more than 10 contiguous pixel defects
along a single column.
Row defects none Horizontal grouping of more than 10 contiguous pixel defects
along a single row.
 Test conditions
 Nominal light = illumination at 80% of saturation
 Temperature of camera is 45°C
 At exposures lower than 0.25 seconds
 At nominal sensor gain (1x)
