82  Operational Reference Falcon™ 4-CLHS Series

Type Value Description Available Bit

bit2: GPO0

bit3: GPO1

bit4: GPO2

bit5: GPO3

bit6: GPO4

bit7: CLHS Trigger

unsigned long long Analog Gain Analog gain. Values returned in units of 0.1

gain. For example, 30 = 3.0.

unsigned long long Digital Gain Digital gain, as raw gain. 4

unsigned long long Factory Gain Factory gain, as raw gain. 4

unsigned short Offset X Offset X, in pixels. 10

unsigned short Offset Y Offset Y, in pixels

unsigned int Counter Value at Reset Counter1 value at reset. 16

unsigned short Width Image width (size X), in pixels. 11

unsigned short Height Image height (size Y), in pixels.

unsigned int Reserved Not used.

unsigned long long Timestamp Timestamp (in microseconds) of the start of the

frame’s acquisition, as identified by the

camera’s internal Timestamp clock.

unsigned long long Binning Binning is coded using the first byte (pixel 80):

Bits [0:3]: binning horizontal

Bits [4:7]: binning vertical

For example, no binning is indicated by 1 in

horizontal and 1 in vertical:

0001 0001 (decimal = 17)

unsigned long long Test Image Selector Test pattern image. Possible values are:

255: Off

0: GreyHorizontalRamp

1: GreyVerticalRamp

9: GreyDiagonalRampMoving

unsigned char [16] Serial Number ASCII codes for device serial number. 29

unsigned char [16] Device User ID ASCII codes for Device User ID. 30

unsigned long long Pixel Format Pixel format. Possible values are:

0x01080001: Mono8

0x01100003: Mono10

unsigned long long Exposure Delay Exposure delay. If not used, the default value

10 μs is returned.

unsigned int Reserved Not used.

unsigned long long Number of ROIs The total number or ROIs 27

unsigned short ROI1 Offset X ROI1 Offset X, in pixels.

unsigned short ROI1 Offset Y ROI1 Offset Y, in pixels.

unsigned short ROI1 Size X ROI1 Size X, in pixels.

unsigned short ROI1 Size Y ROI1 Size Y, in pixels.

unsigned short … …

unsigned short ROI32 Offset X ROI32 Offset X, in pixels.

unsigned short ROI32 Offset Y ROI32 Offset Y, in pixels.

unsigned short ROI32 Size X ROI32 Size X, in pixels.

unsigned short ROI32 Size Y ROI32 Size Y, in pixels.
