36 ï‚· Operational Reference Falconâ„¢ 4-CLHS Series
Line Name
lineName Description of the physical Pin associated with the
logical line.
1.00
Beginner
DFNC
Input 1 Input1 Associated with the logical line Input 1
Input 2 Input2 Associated with the logical line Input 2
Output 1 Output1 Associated with the logical line Output 1
Output 2 Output2 Associated with the logical line Output 2
Output 3 Output3 Associated with the logical line Output 3
Output 4 Output4 Associated with the logical line Output 4
Line Format LineFormat Specify the current electrical format of the selected
physical input or output.
1.00
Beginner
Opto-Coupled OptoCoupled The line is opto-coupled.
Line Mode LineMode
Reports if the physical Line is an Input or Output
signal.
1.00
Beginner
Input Input The line is an input line.
Output Output The line is an output line.
Line Status LineStatus Returns the current status of the selected input line.
1.00
Expert
Low Low Line level is low
High High Line level is high
Line Status All LineStatusAll Returns the current status of all available line signals,
at time of polling, in a single bitfield. The order is
Line1, Line2, Line3, ...
1.01
Expert
Line Inverter LineInverter Controls whether to invert the polarity of the selected
input or output line signal.
1.00
Beginner
Off Off Leave signal unchanged
On On Invert line signal
Input Line Detection Level lineDetectionLevel Specifies the voltage threshold required to recognize a
signal transition on an input line.
1.00
Beginner
DFNC
Threshold for TTL Threshold_for_TTL
A signal below 0.8V will be detected as a Logical LOW
and a signal greater than 2.4V will be detected as a
Logical HIGH on the selected input line.
Input Line Debouncing
Period
lineDebouncingPeriod
Specifies the minimum delay before an input line
voltage transition is recognized as a signal transition.
1.00
Beginner
DFNC
Output Line Source outputLineSource
Selects which internal signal, event driven pulse or
software control state to output on the selected Line.
LineMode must be Output.
1.00
Beginner
DFNC
Off Off
Line output is disabled (Tri-State) or Open with
Optocoupled output.
Software Controlled SoftwareControlled
The OutputLineValue feature changes the state of the
output.
Pulse On: Start of Frame PulseOnStartofFrame Generate a pulse on the start of the Frame Active
event.
Pulse On: Start to Exposure PulseOnStartofExposure Generate a pulse on the ExposureStart event.
Pulse On: End of Exposure PulseOnEndofExposure Generate a pulse on the End of Exposure event.
Pulse On: Start Of Readout PulseOnStartOfReadout Generate a pulse on the ReadoutStart event.
Pulse On: End Of Readout PulseOnEndOfReadout Generate a pulse on the ReadoutEnd event.
Pulse On: Valid Frame
Trigger
PulseOnValidFrameTrigger Generate a pulse on the FrameTrigger event.
Pulse On: Invalid Frame
Trigger
PulseOnInvalidFrameTrigger Generate a pulse on the Invalid Frame(s)Trigger event.
Pulse On: End of Timer1 PulseOnEndofTimer1 Generate a pulse on the end of timer1.
Pulse On: End of Counter1 PulseOnEndofCounter1 Generate a pulse on the end of counter1.
Pulse On: Input1 PulseOnInput1 Generate a pulse on the Input Signal 1 event.
Pulse On: Input2 PulseOnInput2 Generate a pulse on the Input Signal 2 event.
Pulse On: Link CLHS In PulseOnLinkTrigger0 Generate a pulse on LinkTrigger0 signal.
Exposure Active ExposureActive Generate the Exposure Active state on specific output.
