Dalsa Falcon 4-CLHS Series User Manual

Falcon™ 4-CLHS Series Operational Reference  67
Counter Incremental
Source
counterIncrementalSource Select the event source which increments the counter. The
Event Control section provides details and timing diagrams
for the supported events.
1.00
Beginner
DFNC
Off Off Counter is stopped.
Exposure Start ExposureStart Counts the number of Exposure Start events.
ExposureEnd ExposureEnd Counts the number of Exposure End events.
Readout Start ReadoutStart Counts the number of Readout Start events.
Readout End ReadoutEnd Counts the number of Readout End events.
Frame Start FrameStart Counts the number of Frame Start events.
Valid Frame Trigger ValidFrameTrigger Counts the number of Valid Frame Triggers.
Frame Burst FrameBurstEnd Counts the number of multi-frame end triggers.
CLHS In LinkTrigger0 Counts the number of transitions on LinkTrigger0.
Line 1 Line1
Counts the number of transitions on Line 1 (based on the
counterIncrementalLineActivation feature setting)
See Input Signals Electrical Specifications.
Line 2 Line2
Counts the number of transitions on Line 2 (based on the
counterIncrementalLineActivation feature setting)
Invalid Frame Trigger InvalidFrameTrigger Counts the number of rejected frame triggers.
Internal Clock InternalClock The counter increments on each microsecond tick of the
device internal Clock.
Timer 1 End Timer1End Counts the number of Timer 1 End events.
Counter Incremental Line
Activation
counterIncrementalLineActivation Selects the counter signal activation mode. The counter
increments on the specified signal edge or level.
1.00
Beginner
DFNC
Rising Edge RisingEdge Increment the counter on the rising edge of the selected
I/O Line.
Falling Edge FallingEdge
Increment the counter on the falling edge of the selected
I/O Line.
Any Edge AnyEdge Increment the counter on the falling or rising edge of the
selected I/O Line.
Counter Duration counterDuration Sets the duration (or number of events) before the
CounterEnd event is generated.
1.00
Beginner
DFNC
Counter Reset Source counterResetSource Selects the signal source to reset the counter. After a reset
the counter waits for the next countStartSource signal or
event.
1.00
Beginner
DFNC
Off Off Reset on reception of the Reset Icommand.
Exposure Start ExposureStart Reset on reception of the Exposure Start event.
Exposure End ExposureEnd Reset on reception of the Exposure End event.
Readout Start ReadoutStart Reset the counter on the reception of the Readout Start
event.
Readout End ReadoutEnd
Reset the counter on the reception of the Readout End
event.
Frame Start FrameStart Reset on reception of the Frame Start.
Valid Frame Trigger ValidFrameTrigger Reset on reception of the Valid Frame Trigger.
Invalid Frame Trigger InvalidFrameTrigger Reset on reception of the Invalid Frame Trigger.
FrameBurst End Trigger FrameBurstEnd Reset on reception of the Frame Burst end.
Line 1 Line1
Reset counter on the specified transition on line 1.
See Input Signals Electrical Specifications.
Line 2 Line2 Reset counter on the specified transition on line 2.
CLHS In Link0Trigger Reset on reception of CLHS In (Link0Trigger).
Timer 1 End Timer1End Reset on reception of the Timer End.
Counter 1 End Counter1End Reset on the reception of the Counter end.
