Dalsa Xtium-CL MX4 - External Receiver Electrical Requirements; Figure 33:Rev A1: Output Signals Connection Diagram

104 • Technical Specifications Xtium-CL MX4 User's Manual
J1: External Signals Connector
(DH
60-
27P)
Reserved
Reserved
4
To External Devices
Xtium-CL MX4 rev. A1
26
27
:
:
Vcc
3
Vcc
Compatible
Receiver
Compatible
Receiver
2
Vcc
Compatible
Receiver
1
Vcc
Compatible
Receiver
User Signal Ground
Reserved
25 :
Reserved24
:
Reserved23
:
General Output
422 :
General Output
321 :
Reserved
Reserved
19
20
:
:
Reserved18 :
Reserved17 :
General Input 416 :
General Input 315 :
Power (12 Volts)14 :
Ground13
:
General Output 212 :
General Output
1 /
Strobe11 :
Ground10 :
General Input 2 / Trigger 29 :
General Input 1 / Trigger
18 :
Input Common Ground7 :
Shaft Encoder B (+)6 :
Shaft Encoder B (-)5 :
Ground
4
:
Shaft Encoder A (+)3 :
Shaft Encoder A
(
-
)
2 :
Ground1 :
Figure 33:Rev A1: Output Signals Connection Diagram
External Receiver Electrical Requirements
 Xtium General Outputs are standard TTL logic levels.
 External receiver circuits must be compatible to TTL signals.
Input Level Description MIN MAX
TTL
Input Voltage High (V
IH
)
2.0 V –
Input Voltage Low (V
IL
)
– 0.8 V
