Xtium-CL MX4 User's Manual Xtium-CL MX4 Reference • 83
General Inputs #1: Related Capabilities (GIO Module #1)
These are the User Interface Inputs available on connector J1 and J4.
Capability Values
CORGIO_CAP_IO_COUNT 4 I/Os
CORGIO_CAP_DIR_OUTPUT 0x0
CORGIO_CAP_DIR_TRISTATE 0x0
CORGIO_CAP_EVENT_TYPE
CORGIO_VAL_EVENT_TYPE_RISING_EDGE (0x1)
CORGIO_VAL_EVENT_TYPE_FALLING_EDGE (0x2)
CORGIO_CAP_READ_ONLY 0x03 (* depends on external trigger inputs reserved for acquisition device)
General Inputs #1: Related Parameters (GIO Module #1)
Parameter Values
CORGIO_PRM_LABEL General Inputs #1
CORGIO_PRM_DEVICE_ID 1
CORGIO_PRM_INPUT_LEVEL CORGIO_VAL_INPUT_LEVEL_TTL (0x1)
CORGIO_VAL_INPUT_LEVEL_422 (0x2)
CORGIO_VAL_INPUT_LEVEL_24VOLTS (0x8)
CORGIO_VAL_INPUT_LEVEL_12VOLTS (0x40)
CORGIO_PRM_CONNECTOR CORGIO_VAL_CONNECTOR_1 (0x1)
Bidirectional General I/Os: Related Capabilities (GIO Module
#2)
These are the Open Interface I/Os available on connector J5.
Capability Values
CORGIO_CAP_IO_COUNT 8 I/Os
CORGIO_CAP_DIR_OUTPUT 0xff
CORGIO_CAP_DIR_TRISTATE 0xff
CORGIO_CAP_EVENT_TYPE Not Available
CORGIO_CAP_READ_ONLY 0x03 (* depends on board syncs reserved for acquisition device)
Bidirectional General I/Os: Related Parameters (GIO Module
#2)
Parameter Values
CORGIO_PRM_LABEL Bidirectional General I/Os #1
CORGIO_PRM_DEVICE_ID 2
CORGIO_PRM_OUTPUT_TYPE CORGIO_VAL_OUTPUT_TYPE_LVTTL (0x20)
CORGIO_PRM_INPUT_LEVEL CORGIO_VAL_INPUT_LEVEL_LVTTL (0x20)
CORGIO_PRM_CONNECTOR CORGIO_VAL_CONNECTOR_2 (0x2)
