Xtium-CL MX4 User's Manual Xtium-CL MX4 Reference • 63
Transfer Events
Transfer events are the ones related to the transfer module. Transfer events provide feedback on
image transfer from onboard memory frame buffers to PC memory frame buffers.
Event Description
Start of Frame
Start of Frame event generated when the first image pixel is transferred from on-
board memory into PC memory.
The Sapera event value is CORXFER_VAL_EVENT_TYPE_START_OF_FRAME.
End of Frame
End of Frame event generated when the last image pixel is transferred from on-
board memory into PC memory.
The Sapera event value is CORXFER_VAL_EVENT_TYPE_END_OF_FRAME.
End of Line
The End of Line event is generated after a video line is transferred to a PC buffer.
The Sapera event value is CORXFER_VAL_EVENT_TYPE_END_OF_LINE.
End of N Lines
The End of N Lines event is generated after a set number of video lines are
transferred to a PC buffer. The Sapera event value is
CORXFER_VAL_EVENT_TYPE_END_OF_NLINES.
End of Transfer
End of Transfer event generated at the completion of the last image transfer from
on-board memory into PC memory. Issue a stop command to the transfer module
to complete a transfer (if transfers are already in progress). If a frame transfer of
a fixed number of images is requested, the transfer module will stop transfer
automatically. The Sapera event value is
CORXFER_VAL_EVENT_TYPE_END_OF_TRANSFER.
