18 • Installing Xtium-CL MX4 Xtium-CL MX4 User's Manual
Xtium-CL MX4 Firmware Loader
The Device Manager-Firmware Loader program automatically executes at the end of the driver
installation and on every subsequent reboot of the computer. It will determine if the Xtium-CL MX4
requires a firmware update. If firmware is required, a dialog displays. This dialog also allows the
user to load firmware for alternate operational modes of the Xtium-CL MX4.
Important: In the rare case of firmware loader errors please see Recovering from a Firmware
Update Error.
Firmware Update: Automatic Mode
Click Automatic to update the Xtium-CL MX4 firmware. The Xtium-CL MX4 supports various
firmware configurations with the default being a Full, Medium, or Base camera.
for details on all supported modes, selected via a manual firmware update.
With multiple Xtium-CL MX4 boards in the system, all are updated with new firmware. If any
installed Xtium-CL MX4 board installed in a system already has the correct firmware version, an
update is not required. In the following screen shot, a single Xtium-CL MX4 Full board is installed
and ready for a firmware upgrade.
Figure 1: Automatic Firmware Update
