Transfer Related Parameters
Parameter Values
CORXFER_PRM_EVENT_TYPE
CORXFER_PRM_EVENT_TYPE_EX
CORXFER_VAL_EVENT_TYPE_START_OF_FRAME
CORXFER_VAL_EVENT_TYPE_END_OF_FRAME
CORXFER_VAL_EVENT_TYPE_END_OF_TRANSFER
CORXFER_VAL_EVENT_TYPE_END_OF_LINE
CORXFER_VAL_EVENT_TYPE_END_OF_NLINES
CORXFER_PRM_START_MODE
CORXFER_VAL_START_MODE_ASYNCHRONOUS (0x0)
CORXFER_VAL_START_MODE_SYNCHRONOUS (0x1)
CORXFER_VAL_START_MODE_HALF_ASYNCHRONOUS (0x2)
CORXFER_VAL_START_MODE_SEQUENTIAL (0x3)
CORXFER_PRM_CYCLE_MODE
CORXFER_VAL_CYCLE_MODE_ASYNCHRONOUS (0x0)
CORXFER_VAL_CYCLE_MODE_SYNCHRONOUS_WITH_TRASH (0x2)
CORXFER_VAL_CYCLE_MODE_OFF (0x3)
CORXFER_VAL_CYCLE_MODE_SYNCHRONOUS_NEXT_EMPTY_WITH_TRASH (0x5)
CORXFER_PRM_FLIP CORXFER_VAL_FLIP_OFF (0x0)
CORXFER_VAL_FLIP_VERT (0x2)
CORXFER_PRM_INT_BUFFERS * Depends on acquired image size.
By default driver will optimize the number of on-board buffers.
CORXFER_PRM_EVENT_COUNT_SOURCE
CORXFER_VAL_EVENT_COUNT_SOURCE_DST (0x1)
CORXFER_VAL_EVENT_COUNT_SOURCE_SRC (0x2)
CORXFER_PRM_BUFFER_TIMESTAMP_MODULE
CORXFER_VAL_BUFFER_TIMESTAMP_MODULE_ACQ (0x1)
CORXFER_VAL_BUFFER_TIMESTAMP_MODULE_XFER (0x13)
CORXFER_PRM_BUFFER_TIMESTAMP_EVENT (ACQ
Related)
CORACQ_VAL_EVENT_TYPE_START_OF_FRAME (0x80000)
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER (0x1000000)
CORXFER_PRM_BUFFER_TIMESTAMP_EVENT (XFER
Related)
CORXFER_VAL_EVENT_TYPE_END_OF_FRAME (0x800000)
CORXFER_PRM_LINE_MERGING
CORXFER_VAL_LINE_MERGING_AUTO (0x0)
CORXFER_VAL_LINE_MERGING_OFF (0x2)
General Outputs #1: Related Capabilities (GIO Module #0)
These are the User Interface Outputs available on connector J1 and J4.
Capability Values
CORGIO_CAP_IO_COUNT Rev A1: 4 I/Os, Rev A2: 8 I/Os
CORGIO_CAP_DIR_OUTPUT 0xf
CORGIO_CAP_DIR_TRISTATE 0xf
CORGIO_CAP_EVENT_TYPE Not Available
CORGIO_CAP_READ_ONLY 0x03 (* depends on strobe outputs reserved for acquisition device)
General Outputs #1: Related Parameters (GIO Module #0)
Parameter Values
CORGIO_PRM_LABEL General Outputs #1
CORGIO_PRM_DEVICE_ID 0
CORGIO_PRM_OUTPUT_TYPE CORGIO_VAL_OUTPUT_TYPE_LVTTL (0x20)
CORGIO_PRM_CONNECTOR CORGIO_VAL_CONNECTOR_1 (0x1)
