Xtium-CL MX4 User's Manual Xtium-CL MX4 Reference • 75
VIC Related Parameters
Parameter Values
CORACQ_PRM_CAMSEL
Base/Full Mono
10T8B Mono
8T10B Mono
Full Packed RGB
Full Packed RGBY
Base/Full Bayer
80B Packed Bi-Color
10T8B Bayer
8T10B Bayer
Base/Medium Color RGB
80B Packed RGB
CAMSEL_MONO = from 0 to 0
CAMSEL_RGB = from 0 to 0
CORACQ_PRM_CROP_LEFT Base/Full Mono
10T8B Mono
Base/Full Bayer
10T8B Bayer
8T10B Mono
8T10B Bayer
Base/Medium Color RGB
Full Packed RGB
Full Packed RGBY
80B Packed RGB
80B Packed Bi-Color
min = 0 pixel, max = 65512 pixel, step = 2 pixel
min = 0 pixel, max = 65506 pixel, step = 4 pixel
min = 0 pixel, max = 65512 pixel, step = 1 pixel
min = 0 pixel, max = 65512 pixel, step = 1 pixel
min = 0 pixel, max = 32744 pixel, step = 2 pixel
min = 0 pixel, max = 32744 pixel, step = 4 pixel
min = 0 pixel, max = 16380 pixel, step = 1 pixel
min = 0 pixel, max = 16380 pixel, step = 1 pixel
min = 0 pixel, max = 32764 pixel, step = 1 pixel
CORACQ_PRM_CROP_TOP
min = 0 line
max = 16777215 line
step = 1 line
CORACQ_PRM_CROP_WIDTH Base/Full Mono
10T8B Mono
Base/Full Bayer
10T8B Bayer
8T10B Mono
8T10B Bayer
Base/Medium Color RGB
Full Packed RGB
Full Packed RGBY
80B Packed RGB
80B Packed Bi-Color
min = 24 pixel, max = 65536 pixel, step = =2 pixel
min = 24 pixel, max = 65530 pixel, step = =4 pixel
min = 24 pixel, max = 65536 pixel, step = 1 pixel
min = 24 pixel, max = 65536 pixel, step = 1 pixel
min = 24 pixel, max = 32768 pixel, step = 2 pixel
min = 24 pixel, max = 32768 pixel, step = 1 pixel
min = 4 pixel, max = 16384 pixel, step = 1 pixel
min = 4 pixel, max = 16384 pixel, step = 1 pixel
min = 4 pixel, max = 32768 pixel, step = 1 pixel
CORACQ_PRM_CROP_HEIGHT
min = 1 line
max = 16777215 line
step = 1 line
CORACQ_PRM_DECIMATE_METHOD CORACQ_VAL_DECIMATE_DISABLE (0x1)
CORACQ_PRM_LUT_ENABLE Full Packed RGBY
All other modules
Not Available
TRUE
FALSE
CORACQ_PRM_LUT_NUMBER Default = 0
CORACQ_PRM_STROBE_ENABLE TRUE
FALSE
CORACQ_PRM_STROBE_METHOD CORACQ_VAL_STROBE_METHOD_1 (0x1)
CORACQ_VAL_STROBE_METHOD_3 (0x4)
CORACQ_VAL_STROBE_METHOD_4 (0x8)
CORACQ_PRM_STROBE_POLARITY
CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_STROBE_DURATION
min = 1 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_STROBE_DELAY min = 0 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_ENABLE TRUE
FALSE
