Xtium-CL MX4 User's Manual Technical Specifications • 97
Xtium-CL MX4 rev. A1
Description Pin # Pin # Description
Ground 1 15 General Input 3
RS-422 Shaft Encoder Phase A (-) 2 16 General Input 4
RS-422 Shaft Encoder Phase A (+)
(see note 3
)
3 17 Reserved
Ground 4 18 Reserved
RS-422 Shaft Encoder Phase B (-) 5 19 Reserved
RS-422 Shaft Encoder Phase B (+) 6 20 Reserved
General Input Common
External Trigger Input 1 (-)
General Input 1 (-)
7 21 General Output 3
External Trigger Input 1 (+)
General Input 1 (+)
(Opto-coupled — see note 1
)
8 22 General Output 4
External Trigger Input 2
General Input 2
9 23 Reserved
Ground 10 24 Reserved
Strobe 1
General Output 1
(See note 2
)
11 25 Reserved
Strobe 2
General Output 2
12 26 Reserved
Ground 13 27 Reserved
Power Output 12 Volts, 350mA max
(from Aux Power Connector, see J7
below)
14
