J1: External Signals Connector (Female DH60-27P)
Warning: J1 and J4 have the same pinout assignment. Signals are routed to both connectors
directly from their internal circuitry. Therefore never connect both J1 and J4 to external
devices at the same time.
See DH40-27S Cable to Blunt End (OR-YXCC-27BE2M1, Rev B1) and Cable assemblies for I/O
connector J4 for available cables.
J4: Internal I/O Signals Connector (26-pin SHF-113-01-L-D-
RA)
Important: The table below describes the I/O signals available on both J1 and J4.
(applies to Xtium-CL MX4 rev. A2)
Use only one of the two I/O connectors — never both!
Xtium-CL MX4 rev. A2
Description Pin # Pin # Description
Ground 1 15 General Input 3 (+)
RS-422 Shaft Encoder Phase A (-) 2 16 General Input 4 (+)
RS-422 Shaft Encoder Phase A (+)
(see note 3
)
3 17 General Input 4 (-)
Ground 4 18 General Input 3 (-)
RS-422 Shaft Encoder Phase B (-) 5 19 Power Output 5 Volts, 100mA max
RS-422 Shaft Encoder Phase B (+) 6 20
External Trigger Input 2 or
General Input 2 (-)
External Trigger Input 1/General Input 1 (-) 7 21 General Output 3
External Trigger Input 1/General Input 1 (+)
8 22 General Output 4
External Trigger Input 2/General Input 2 (+) 9 23 General Output 5
Ground 10 24 General Output 6
Strobe 1 / General Output 1
(See note 2
)
11 25 General Output 7
Strobe 2 / General Output 2
(See note 2
)
12 26 General Output 8
Ground 13 27 NC
Power Output 12 Volts, 350mA max
(from Aux Power Connector, see J7)
14
Important: The table below describes the I/O signals available on both J1 and J4.
(applies to Xtium-CL MX4 rev. A1)
Use only one of the two I/O connectors — never both!
