94 • Technical Specifications Xtium-CL MX4 User's Manual
J2: Camera Link Connector 2
Medium and Full Camera Link sources require cables connected to both J2 and J3.
Name Pin # Type Description
MEDIUM _X0- 25 Input Neg. Medium Data 0
MEDIUM _X0+ 12 Input Pos. Medium Data 0
MEDIUM _X1- 24 Input Neg. Medium Data 1
MEDIUM _X1+ 11 Input Pos. Medium Data 1
MEDIUM _X2- 23 Input Neg. Medium Data 2
MEDIUM _X2+ 10 Input Pos. Medium Data 2
MEDIUM _X3- 21 Input Neg. Medium Data 3
MEDIUM _X3+ 8 Input Pos. Medium Data 3
MEDIUM _XCLK- 22 Input Neg. Medium Clock
MEDIUM _XCLK+ 9 Input Pos. Medium Clock
TERM 20 Term Resistor
TERM 7 Term Resistor
FULL_X0- 19 Input Neg. Full Data 0
FULL _X0+ 6 Input Pos. Full Data 0
FULL _X1- 18 Input Neg. Full Data 1
FULL _X1+ 5 Input Pos. Full Data 1
FULL _X2- 17 Input Neg. Full Data 2
FULL _X2+ 4 Input Pos. Full Data 2
FULL _X3- 15 Input Neg. Full Data 3
FULL _X3+ 2 Input Pos. Full Data 3
FULL _XCLK- 16 Input Neg. Full Clock
FULL _XCLK+ 3 Input Pos. Full Clock
PoCL 1,26 +12 V (see note following table)
GND 13, 14 Ground
Notes on PoCL support:
Refer to Sapera’s parameter CORACQ_PRM_POCL_ENABLE to enable PoCL and
CORACQ_PRM_SIGNAL_STATUS/CORACQ_VAL_SIGNAL_POCL_ACTIVE_2 to verify if the POCL
is active. See also Sapera++ reference parameter SapAcquisition::SignalPoCLActive for the
current state.
PoCL state is maintained as long as the board is not reset
