Technical Specifications
Xtium-CL MX4 Board Specifications
Digital Video Input & Controls
Input Type Camera Link Specifications Rev 2.0 compliant;
2 Base or 1 Full or 1 Medium or 1 80-bit
(using SDR-26 Camera Link connectors — MiniCL)
Supports PoCL cameras in:
Camera Link Base, Medium, Full/80-Bit Configurations
Common Pixel Formats Camera Link tap configuration:
8, 10, 12, 14 and 16-bit mono
8, 10, 12-bit RGB
8, 10, 12-bit Bayer
8-bit Bi-Color
Tap Format Details
1 Tap – 8/10/12/14/16-bit mono
2 Taps – 8/10/12-bit mono
3 Taps – 8/10/12-bit mono
4 Taps – 8/10/12-bit mono
8 Taps – 8-bit mono
8 Taps – 10-bit mono
10 Taps – 8-bit mono
1 Tap – 8/10/12-bit RGB
2 Taps – 8-bit RGB
Full packed 8-bit RGB/BGR
Full packed 8-bit RGBY
80-bit packed 8/12-bit RGB/BGR
80-bit packed 8-bit Bi-Color
Scanning Area scan and Line scan: Progressive, Segmented, Multi-Tap, Tap reversal,
Alternate Tap Configuration, Dual Channel
Scanning Directions
Left to Right, Right to Left, Up-Down,
From Top
Resolution
note: these are Xtium-
CL
MX4 maximums, not
Camera Link
specifications
Horizontal Minimum:
8 Pixels per tap (8-bits/pixel)
Horizontal Maximum:
8-bits/pixel x 64k Pixels/line
16-bits/pixel x 32k Pixels/line
32-bits/pixel x 16k Pixels/line
64-bits/pixel x 8k Pixels/line
Vertical Minimum:
1 line
Vertical Maximum:
up to 65536 lines—for area scan sensors
infinite line count—for line scan sensors
Pixel Clock Range 20 MHz to 85 MHz
Synchronization
Minimums
Horizontal Sync minimum: 1 pixel
Vertical Sync minimum: 1 line
Image Buffer Available with 512 MB
Bandwidth to Host
System
Approximately 1.7GB/s (maximum obtained is dependent on firmware
loaded and PC characteristics)
Serial Port Supports communication speeds from 9600 to 921600 bps
