Xtium-CL MX4 User's Manual Technical Specifications • 87
Controls Compliant with Teledyne DALSA Trigger-to-Image Reliability framework
Comprehensive event notifications
Timing control logic for camera triggers and strobe signals
External trigger latency less than 100 nsec
Supports multi-board / multi-camera synchronization
Quadrature (phase A & B) shaft encoder inputs for external web
synchronization: RS-422 input maximum frequency is 5 MHz
4 differential opto-coupled general inputs (RS-422/TTL/12V/24V).
Can be used as opto-coupled external trigger inputs programmable as
active high or low (edge or level trigger).
(only 1 input can be connected to a differential input signal on Rev A1)
8 LVTTL general outputs. Can be used as Strobe outputs. (4 on Rev A1)
I/O available on a DH60-27P connector (J1)
and on 26-pin SHF-113-01-L-D-RA (J4)
Processing
Dependant on user
loaded firmware
configuration
Output Lookup Table
Bayer Mosaic Filter
Bi-Color Conversion (for TDALSA P4)
Flat Field/Flat Line Correction
