Xtium-CL MX4 User's Manual Overview • 7
Overview
Product Part Numbers
Xtium-CL MX4 Board
Item Product Number
Xtium-CL MX4 OR-Y4C0-XMX00
For OEM clients, this manual in printed form, is available on request. OC-Y4CM-MUSR0
Xtium-CL MX4 Software
Item Product Number
Sapera LT version 8.20 or later for full feature support (required but sold
separately).
1. Sapera LT: Provides everything needed to build imaging
application.
2. Current Sapera-compliant board hardware drivers
3. Sapera documentation (compiled HTML help, Adobe Acrobat®
(PDF)
OC-SL00-0000000
(optional) Sapera Processing Imaging Development Library includes over 600
optimized image-processing routines.
Contact Sales at
Teledyne DALSA
Optional Xtium-CL MX4 Cables & Accessories
Item Product Number
DH60-27S cable assembly to blunt end:
6 ft cable I/O 27 pin Hirose connector to blunt end.
This cable assembly connects to J1.
(see "J1: External Signals Connector (Female DH60-27P))
OR-YXCC-27BE2M1, Rev B1
Cable set to connect to J4 Internal I/O Signals connector
(J4: 26-pin SHF-113-01-L-D-RA)
See suggested cables
DH40-27S Connector Kit for Custom Wiring:
Comprised of a DH40-27S connector plus screw lock housing kit
OR-YXCC-H270000
Cable assembly to connect to J5 (Board Sync)
Connecting 2 boards
Connection 3 or 4 boards
OR-YXCC-BSYNC20
OR-YXCC-BSYNC40
Power interface cable required when supplying power to cameras and/or
J1/J4
OR-YXCC-PWRY00
Power Over Camera Link (PoCL) Video Input Cable
2 meter HDR to MDR
2 meter HDR to HDR
OR-COMC-POCLD2
OR-COMC-POCLDH
