Xtium-CL MX4 Supported Parameters
The tables below describe the Sapera capabilities supported by the Xtium-CL MX4. Unless specified,
each capability applies to all configuration modes and all acquisition modes.
The information here is subject to change. The application needs to verify capabilities. New board
driver releases may change product specifications.
Sapera describes the Xtium-CL MX4 family as:
• Board Server: Xtium-CL_MX4_1
• Acquisition Module: dependent on firmware used
Camera Related Capabilities
Capability Values
CORACQ_CAP_CONNECTOR_TYPE CORACQ_VAL_CONNECTOR_TYPE_CAMLINK (0x2)
CORACQ_CAP_CONNECTOR_CAMLINK
(Pin – 01, Pin – 02, Pin – 03, Pin - 04)
CORACQ_VAL_SIGNAL_NAME_NO_CONNECT (0x1)
CORACQ_VAL_SIGNAL_NAME_PULSE0 (0x8)
CORACQ_VAL_SIGNAL_NAME_PULSE1 (0x10)
CORACQ_VAL_SIGNAL_NAME_GND (0x4000)
CORACQ_VAL_SIGNAL_NAME_EXT_TRIGGER_1 (0x200)
CORACQ_VAL_SIGNAL_NAME_EXT_TRIGGER_2 (0x200000)
CORACQ_VAL_SIGNAL_NAME_SHAFT_ENCODER_PHASE_A (0x40000)
CORACQ_VAL_SIGNAL_NAME_SHAFT_ENCODER_PHASE B (0x80000)
CORACQ_VAL_SIGNAL_NAME_EXT_LINE_TRIGGER_1 (0x400)
CORACQ_VAL_SIGNAL_NAME_EXT_LINE_TRIGGER_2 (0x100000)
