Xtium-CL MX4 User's Manual Xtium-CL MX4 Reference • 81
CORACQ_CAP_FLAT_FIELD_GAIN
8-bit Mono
10-bit Mono
12-bit Mono
14-bit Mono
16-bit Mono
min = 0
max = 255
step = 1
min = 0
max = 4095
step = 1
min = 0
max = 16383
step = 1
min = 0
max = 65535
step = 1
Not Available
CORACQ_CAP_FLAT_FIELD_GAIN_DIVISOR 8-bit Mono
10-bit Mono
12-bit Mono
14-bit Mono
16-bit Mono
128
512
2048
8192
Not Available
CORACQ_PRM_FLAT_FIELD_PIXEL_REPLACEMENT
_METHOD
CORACQ_VAL_FLAT_FIELD_PIXEL_REPLACEMENT_METHOD_2
(Pixel replacement is done by averaging the 2 neighborhood pixels. When one
of the neighbors is not available (border image pixels, the pixel is simply
replaced with the available neighbor)
CORACQ_VAL_FLAT_FIELD_PIXEL_REPLACEMENT_METHOD_3
(Pixel replacement is done by averaging neighborhood pixels using a 3x2
kernel)
CORACQ_PRM_FLAT_FIELD_SET_SELECT
min = 0
max = 16
step = 1
CORACQ_PRM_TIME_STAMP Available
CORACQ_PRM_IMAGE_FILTER_ENABLE Not Available
CORACQ_PRM_SHAFT_ENCODER_REVERSE_COUNT Max = 65536 ticks
CORACQ_PRM_META_DATA CORACQ_VAL_META_DATA_PER_LINE_RIGHT (0x2)
CORACQ_CAP_SERIAL_PORT_INDEX Supported
Transfer Related Capabilities
Capability Values
CORXFER_CAP_NB_INT_BUFFERS CORXFER_VAL_NB_INT_BUFFERS_AUTO (0x2)
CORXFER_CAP_MAX_XFER_SIZE 4294967040 Bytes
CORXFER_CAP_MAX_FRAME_COUNT 16777215 Frames
CORXFER_CAP_COUNTER_STAMP_AVAILABLE FALSE
