Xtium-CL MX4 User's Manual Xtium-CL MX4 Reference • 65
Output LUT Availability
The following table defines the supported output LUT (look up tables) for the Xtium-CL MX4. Note
that unsupported modes are not listed.
Number of Digital
Bits
Output Pixel
Format
LUT Format Notes*
8
8
MONO 8
MONO 16
8-in, 8-out
8-in, 16-out 8 bits in 8 LSBs of 16-bit
10 MONO 8 10-in, 8-out
10 MONO 16 10-in, 16-out 10 bits in 10 LSBs of 16-bit
12 MONO 8 12-in, 8-out 8 MSB
12 MONO 16 12-in, 16-out 12 bits in 12 LSBs of 16-bit
8 x 3 (RGB) RGB888 8-in, 8-out
8 x 3 (RGB) RGB8888 8-in, 8-out
10 x 3 (RGB) RGB888
RGB8888
RGB101010
RGB16161616
10-in, 8-out
10-in, 8-out
10-in, 10-out
10-in, 16-out 10 bits in 10 LSBs of 16-bit
12 x 3 (RGB) RGB888
RGB8888
RGB101010
RGB16161616
12-in, 8-out
12-in, 8-out
12-in, 10-out
12-in, 16-out 12 bits in 12 LSBs of 16-bit
*When no LUTs are available or LUTs are disabled, the data is packed in the LSBs of the target
destination.
