76 • Xtium-CL MX4 Reference Xtium-CL MX4 User's Manual
CORACQ_PRM_TIME_INTEGRATE_DURATION
min = 1 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_CAM_TRIGGER_ENABLE
TRUE
FALSE
CORACQ_PRM_OUTPUT_FORMAT Base/Full Mono
10T8B / 8T10B
Base/Medium Color RGB
Base/Full Bayer
Full Packed RGB
Full Packed RGBY
80B Packed RGB
80B Packed Bi-Color
10T8B Bayer
8T10B Bayer
CORACQ_VAL_OUTPUT_FORMAT_MONO8
CORACQ_VAL_OUTPUT_FORMAT_MONO16
CORACQ_VAL_OUTPUT_FORMAT_MONO8P2
CORACQ_VAL_OUTPUT_FORMAT_MONO8P3
CORACQ_VAL_OUTPUT_FORMAT_MONO8P4
CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB888
CORACQ_VAL_OUTPUT_FORMAT_RGB101010
CORACQ_VAL_OUTPUT_FORMAT_RGB16161616
CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB888
CORACQ_VAL_OUTPUT_FORMAT_RGB101010
CORACQ_VAL_OUTPUT_FORMAT_RGB16161616
CORACQ_VAL_OUTPUT_FORMAT_MONO8
CORACQ_VAL_OUTPUT_FORMAT_MONO16
CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB888
CORACQ_VAL_OUTPUT_FORMAT_RGB888_MONO8
CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB888
CORACQ_VAL_OUTPUT_FORMAT_RGB101010
CORACQ_VAL_OUTPUT_FORMAT_RGB16161616
CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB888
CORACQ_VAL_OUTPUT_FORMAT_BICOLOR88
CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB888
CORACQ_VAL_OUTPUT_FORMAT_MONO8
CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB888
CORACQ_VAL_OUTPUT_FORMAT_RGB101010
CORACQ_VAL_OUTPUT_FORMAT_RGB16161616
CORACQ_VAL_OUTPUT_FORMAT_MONO16
CORACQ_PRM_EXT_TRIGGER_ENABLE
CORACQ_VAL_EXT_TRIGGER_OFF (0x1)
CORACQ_VAL_EXT_TRIGGER_ON (0x8)
CORACQ_PRM_VIC_NAME Base/Full Mono
10T8B Mono
8T10B Mono
Base/Medium Color RGB
Base/Full Bayer
Full Packed RGB
80B Packed RGB
80B Packed Bi-Color
10T8B Bayer
8T10B Bayer
Full Packed RGBY
Default Area Scan 1 tap Mono
Default Area Scan 10 taps Parallel Mono
Default Area Scan 8 taps Parallel Mono
Default Area Scan 1 tap Color
Default Bayer Area Scan 1 tap Color
Default Area Scan Full Packed RGB
Default Area Scan 80-bit Packed RGB
Default Area Scan 80-bit Packed Bi-Color
Default Bayer Area Scan 10 taps Parallel Color
Default Bayer Area Scan 8 taps Parallel Color
Default Line Scan Full Packed RGBY
CORACQ_PRM_LUT_MAX Full Packed RGBY
All other modules
0
1
CORACQ_PRM_EXT_TRIGGER_DETECTION CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_PRM_LUT_FORMAT Base/Full mono/10T8B
8T10B
Base/Medium Color RGB
Base/Full Bayer
Full Packed RGB
80B Packed RGB
80B Packed Bi-Color
10T8B Bayer
8T10B Bayer
Default = CORDATA_FORMAT_MONO8
Default = CORDATA_FORMAT_MONO16
Default = CORDATA_FORMAT_COLORNI8
Default = CORDATA_FORMAT_COLORNI8
Default = CORDATA_FORMAT_COLORNI8
Default = CORDATA_FORMAT_COLORNI8
Default = CORDATA_FORMAT_COLORNI10
CORACQ_PRM_VSYNC_REF CORACQ_VAL_SYNC_REF_END (0x2)
CORACQ_PRM_HSYNC_REF CORACQ_VAL_SYNC_REF_END (0x2)
CORACQ_PRM_LINE_INTEGRATE_ENABLE
TRUE
FALSE
