78 • Xtium-CL MX4 Reference Xtium-CL MX4 User's Manual
CORACQ_PRM_CAM_TRIGGER_DELAY
min = 0 µs
max = 85899345 µs
step = 1 µs
CORACQ_PRM_SHAFT_ENCODER_LEVEL CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_PRM_LUT_NENTRIES 8-bit/pixel component
10-bit/pixel component
12-bit/pixel component
14/16-bit/pixel component
256 entries
1024 entries
4096 entries
0 entries
CORACQ_PRM_EXT_FRAME_TRIGGER_SOURCE (*) min = 0
max = 5
step = 1
CORACQ_PRM_EXT_LINE_TRIGGER_SOURCE (*)
min = 0
max = 5
step = 1
CORACQ_PRM_EXT_TRIGGER_SOURCE (*)
min = 0
max = 5
step = 1
CORACQ_PRM_SHAFT_ENCODER_MULTIPLY
min = 1
max = 32
step = (2
N
)
CORACQ_PRM_EXT_TRIGGER_DELAY min = 0
max = 16777215
step = 1
CORACQ_PRM_EXT_TRIGGER_DELAY_TIME_BASE CORACQ_VAL_TIME_BASE_LINE_VALID (0x4)
CORACQ_VAL_TIME_BASE_LINE_TRIGGER (0x8)
CORACQ_VAL_TIME_BASE_SHAFT_ENCODER (0x40)
CORACQ_VAL_TIME_BASE_NS (0x80)
CORACQ_PRM_COLOR_DECODER_ENABLE Base/Full Mono
10T8B/8T10B
Base/Medium Color
RGB
Full Packed RGB
Full Packed RGBY
80B Packed RGB
Base/Full Bayer
10T8B Bayer
8T10B Bayer
80B Packed
Bi-Color
Not available
TRUE
FALSE
CORACQ_PRM_COLOR_DECODER_METHOD
Full Bayer
10T8B Bayer
8T10B Bayer
80B Packed
Bi-Color
CORACQ_VAL_COLOR_DECODER_METHOD_1 (0x1)
CORACQ_VAL_COLOR_DECODER_METHOD_7 (0x40)
CORACQ_PRM_WB_GAIN Base/Full Color RGB
Full Packed RGB
80B Packed RGB
80B Packed Bi-Color
Base/Full Bayer
10T8B Bayer
8T10B Bayer
Min = 100000, max = 900000, step = 1
CORACQ_PRM_WB_GAIN_RED
Base/Full Color RGB
Full Packed RGB
80B Packed RGB
80B Packed Bi-Color
Base/Full Bayer
10T8B Bayer
8T10B Bayer
Min = 100000, max = 900000, step = 1
CORACQ_PRM_WB_GAIN_GREEN
Base/Full Color RGB
Full Packed RGB
80B Packed RGB
80B Packed Bi-Color
Base/Full Bayer
10T8B Bayer
8T10B Bayer
Min = 100000, max = 900000, step = 1
CORACQ_PRM_WB_GAIN_BLUE
Base/Full Color RGB
Full Packed RGB
80B Packed RGB
80B Packed Bi-Color
Base/Full Bayer
10T8B Bayer
8T10B Bayer
Min = 100000, max = 900000, step = 1
