Datalogic QuickScan Lite QW2100 User Manual

Product Reference Guide 279
UPC-A Minimum Reads
1 Read
106
UPC/EAN Guard Insertion
Disable
107
UPC/EAN Stitch Exact Label Halves
Disable
107
UPC/EAN Stitch Unlike Label Halves
Disable
108
UPC/EAN Minimum Segment Length
5
109
Add-Ons
Optional Add-ons
Disable P2, P5 and
P8
111
Optional Add-On Timer
70 ms
113
P2 Add-Ons Minimum Reads
2
115
P5 Add-Ons Minimum Reads
1
116
GS1-128 Add-Ons Minimum Reads
1
117
GS1 DataBar Omnidirectional
GS1 DataBar Omnidirectional Enable/
Disable
Disable
118
GS1 DataBar Omnidirectional GS1-128
Emulation
Disable
118
GS1 DataBar Omnidirectional Minimum
Reads
1
119
GS1 DataBar Expanded
GS1 DataBar Expanded Enable/Disable
Disable
120
GS1 DataBar Expanded GS1-128 Emula-
tion
Disable
120
GS1 DataBar Expanded Minimum Reads
1
121
GS1 DataBar Expanded Length Control
Variable
122
GS1 DataBar Expanded Set Length 1
1
123
GS1 DataBar Expanded Set Length 2
74
124
GS1 DataBar Limited
GS1 DataBar Limited Enable/Disable
Disable
125
GS1 DataBar Limited GS1-128 Emulation
Disable
125
GS1 DataBar Limited Minimum Reads
1
126
Parameter Default Your Setting Page Number

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
