Datalogic QuickScan Lite QW2100 User Manual

280 QuickScan
TM
Lite QW2100
Code 39
Code 39 Enable/Disable
Enable
127
Code 39 Check Character Calculation
Calculate
128
Code 39 Check Character Transmission
Send
129
Code 39 Start/Stop Character Transmis-
sion
Don’t Transmit
129
Code 39 Full ASCII
Disable
130
Code 39 Quiet Zones
Auto
131
Code 39 Minimum Reads
2
132
Code 39 Decoding Level
3
133
Code 39 Length Control
Variable
134
Code 39 Set Length 1
2
135
Code 39 Set Length 2
50
136
Code 39 Interdigit Ratio
4
137
Code 39 Character Correlation
Disable
139
Code 39 Stitching
Enable
139
Code 32
Code 32 Enable/Disable
Disable
140
Code 32 Check Character Transmission
Don’t Send
141
Code 32 Start/Stop Character Transmis-
sion
Don’t Transmit
141
Code 39 CIP
Code 39 CIP Enable/Disable
Disable
142
Code 128
Code 128 Enable/Disable
Enable
142
Expand Code 128 to Code 39
Don’t Expand
143
Code 128 Check Character Transmission
Send
143
Code 128 Quiet Zones
Auto
145
Code 128 Minimum Reads
1
146
Code 128 Decoding Level
3
147
Parameter Default Your Setting Page Number

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
