Datalogic SC5100 - Chapter 8. Technical Features

PRODUCT REFERENCE GUIDE 94
CHAPTER 8
TECHNICAL FEATURES
ELECTRICAL FEATURES
Supply Voltage 24 VDC +/1 20%
Power Consumption 2.8 A Max.
Communication Interfaces
Serial Main (isolated)
- RS232
- RS422 full-duplex
1200 to 115200 bits/s
1200 to 115200 bits/s
Serial Aux
- RS232 1200 to 115200 bits/s
Ethernet (x2) TCP/IP 4 Ports Gb/s ETH Switch; Embedded EtherNet/IP
EBC and SyncNet Internal Network 100 Mbit/s
Alibi Storage (only SC5100-102x mod-
els)
“Legal For Trade” Alibi Storage for Scale Weight Data
Fieldbus
- Profibus (only SC5100-1100 model)
- Profinet (only SC5100-1200 model)
- All models
PROFIBUS DP application protocol; up to 12 Mb/s
PROFINET-IO application protocol; 100 Mb/s
Embedded EtherNet/IP; 100 Mb/s
Inputs (main)
3 polarity insensitive optocoupled inputs (5-30 Vdc) :
Trigger, Encoder/Tachometer, IN3,
Outputs (main) 3 optocoupled outputs
Inputs (aux)
3 polarity insensitive optocoupled inputs
Outputs (aux) 3 optocoupled outputs
Input/Output
2 configurable Input/Output (PNP or NPN polarity insensitive
optocoupled input, or optocoupled output)
USER INTERFACE
LCD Display 5 inch graphical color
Keypad 5 keys
