TYPICAL LAYOUTS
Large Synchronized Network Layout
The SC5100 controller can be connected to the host in several different layouts,
depending on the controller model and host interfaces.
External devices (e.g. presence sensor, encoders) are all connected to the SC5100
through a CBX510 connection box using one of the two I/O connectors.
Ethernet TCP/IP to Host
The host can be connected to the controller through an Ethernet direct cable or through
a hub/switch:
