EBC CONNECTION MODULE™
129
SC5100 CONTROLLER
TECHNICAL SPECIFICATIONS
* Consumption of the EBC Connection Module alone. Total Power Consumption is given by adding
the EBC Connection Module power consumption to that of all the devices powered through the
EBC Connection Module (reading device, illuminator). Refer to the manuals of the connected
devices for details about their power consumption.
ELECTRICAL FEATURES
Power
Supply Voltage 24 Vdc
Consumption * 0.05 A
Overcurrent protection 2.6 A
COMMUNICATION INTERFACES
Ethernet
Pigtail (up to 10 Mbps)
EBC (10/100 Mbps)
USER INTERFACE
LED indicators
Power In (Blue)
External Illuminator (Blue)
2 EBC Links (Orange)
PHYSICAL FEATURES
Dimensions
H x W x L
170 x 72 x 32 mm
(6.7 x 2.8 x 1.3 in)
Pigtail cable length
50 mm (2 in)
Weight
435 g (15.3 oz)
Material
Aluminum
