TECHNICAL SPECIFICATIONS
PRODUCT REFERENCE GUIDE
130
** When all the M12 connectors and reading devices are correctly connected (or closed with proper
protection caps).
ENVIRONMENTAL FEATURES
Operating temperature
-10 to 50 °C (+14 to 122 °F)
Storage temperature
-20 to 70 °C (-4 to 158 °F)
Humidity max.
90% non condensing
Sinusoidal vibration resistance EN 60068-2-6
14 mm @ 2 to 10 Hz;
1.5 mm @ 13 to 55 Hz;
2 gn @ 70 to 500 Hz;
2 hours on each axis
Bump resistance EN 60068-2-29
30 g; 6 mm;
5000 shocks on each axis
Shock resistance EN 60068-2-29
30 g; 11 ms;
3 shocks on each axis
Protection class EN 60529
IP65 and IP67**
