CHAPTER 3
ELECTRICAL INSTALLATION
PREPARING FOR ELECTRICAL INSTALLATION
Before mounting any components, please do the following:
• Read all instructions before beginning your installation.
• Observe all electrical safety requirements discussed in the Introduction to this
manual.
• Define and confirm the accuracy of your application’s requirements.
• Review all installation-specific drawings.
• Review and plan the power requirements for your application.
• Review and plan the communications requirements for your application
WARNING: Electrical Installation must be performed by a qualified service
Technician only! Procedures may involve exposure to high voltage. A
trained and authorized technician must perform these procedures. Do not
attempt to perform any electrical installation procedures unless you are a
trained technician.
IMPORTANT: The SC5100 contain electronics that may be affected by elec-
trostatic discharge (ESD). To prevent personal injury or damage to the unit,
please follow the safety precautions and warnings found in the References
section at the beginning of this manual. Failure to follow these precautions
may void your warranty.
IMPORTANT: The content of this manual may be superseded by any cus-
tomer-specific documentation provided by Datalogic. Before proceeding
with any installation procedures, be sure to review ALL documentation,
especially content that contains details specific to your installation.
Everything should be MECHANICALLY INSTALLED before performing any
ELECTRICAL INSTALLATION. See mechanical installation details.
To reduce the possibility of damage to the unit, check all cabling between
the SC5100 Controller and other devices for accuracy.
