3 Copy
132
Paper Size and Stapling Position
• Finisher-B1
* :The staple orientation displayed on the touch screen differs from the actual staple orientation. Outputs are stapled in the
orientation shown in the above table.
Paper Size and Punching Position (Finisher-B1)
•2 holes*
* : For the Finisher-B1, the distance between the two holes is 70 mm with the US 2/3 Hole Punch Kit, and is 80 mm with
the 2/4 Hole Punch Kit, which is ordinary used.
•3 holes
1 Staple
(Left)
1 Staple
(Right)
2 Staples
(Left)
2 Staples
(Top)
2 Staples
(Right)
A4 , B5 ,
7.25 x 10.5" ,
8 x 10" ,
8.5 x 11" ,
16K
A4, A3, B4,
8.5 x 11",
8.5 x 13",
8.5 x 14",
11 x 15",
11 x 17", 8K
*
*
*
*
2 Holes (Left) 2 Holes (Top)
2 Holes
(Right)
A4 , B5 , 7.25 x 10.5" , 8 x 10" ,
8.5 x 11" , 16K
A4, A3, B4, 8 x 10", 8.5 x 11", 8.5 x 13",
11 x 15", 8.5 x 14", 11 x 17", 8K
3 Holes (Left) 3 Holes (Top)
3 Holes
(Right)
A4 , B5 , 7.25 x 10.5" , 8 x 10" ,
8.5 x 11" , 16K
A3, B4, 11 x 15", 11 x 17", 8K
