Configuration of Job Flow Sheets
505
For information on how to set an IP address, refer to "Protocol Settings" (P.363).
5
Select [Close] repeatedly until the [Tools] screen is displayed.
6
Select [Close].
Note • Rebooting the machine may be required depending on the settings. When a message displayed on the
screen, follow the message and reboot the machine.
7
Print a configuration report to confirm that the SOAP, SNMP, and Internet Services
(HTTP) ports are enabled and that TCP/IP is set up correctly.
For information on how to print a configuration report, refer to "Print Reports" (P.276).
Step 2 Configuring the SNMP Port
Configure the transport protocol for the SNMP port using Dell Printer Configuration Web
Tool.
1
Start Dell Printer Configuration Web Tool.
For information on how to start Dell Printer Configuration Web Tool, refer to "Starting Dell Printer
Configuration Web Tool" (P.464).
2
Configure the transport protocol for the SNMP port.
1) Click the [Properties] tab.
2) Click [Connectivity].
3) Click [Port Settings].
4) Select the [UDP] check box under [SNMP].
5) Click [Apply].
6) The right frame of the web browser changes to the machine reboot display.
7) Click [Reboot Machine]. The machine reboots and the settings are enabled.
Step 3 Configuration on the Computer
Create job flows using Job Flow Editor to use for scanned documents.
Note • Job Flow Editor is included in the Driver CD Kit.
To Next Page
