13 Maintenance
258
Replacing Booklet Staple Cartridge (for Booklet Maker Unit for Finisher-B1)
When the optional Booklet Maker Unit for Finisher-B1 is installed and the booklet staple
cartridges need to be replaced, a message appears on the touch screen. When the message
appears, replace the booklet staple cartridges with new ones.
Note • The use of booklet staple cartridges not recommended by Dell may degrade quality and performance.
Use only booklet staple cartridges recommended by Dell.
1
Make sure that the machine is not operating,
and open the finisher side cover.
2
Hold the tabs on both sides of the booklet
staple cartridge and pull it out.
3
Hold the tabs on both sides of a new booklet
staple cartridge, and insert it into the finisher
until it clicks.
4
Do the same for the booklet staple cartridge on the other side.
5
Close the finisher side cover.
Note • If the cover is not closed completely, a message appears and the machine will remain paused.
