17 Printer Environment Settings
482
For information on how to set an IP address, refer to "Protocol Settings" (P.363).
4
Select [Close] repeatedly until the [Tools] screen is displayed.
5
Select [Close].
Note • Rebooting the machine may be required depending on the settings. When a message displayed on the
screen, follow the message and reboot the machine.
6
Print a configuration report to confirm that the SMB port is enabled and that TCP/IP is set
up correctly.
For information on how to print a configuration report, refer to "Print Reports" (P.276).
Note • If NetBEUI protocol is used as the transport protocol, select [NetBEUI] on the [Port Settings] screen
for SMB in Dell Printer Configuration Web Tool.
7
Configure the other SMB settings as necessary.
For information on the SMB settings, refer to "Dell Printer Configuration Web Tool Setting Items"
(P.482).
Step 3 Configuration on the Computer
To print from the machine, you need to install a print driver on your computer.
For information on the supported operating systems, refer to "Supported Operating Systems" (P.472).
For information on the driver installation procedures, refer to the manual contained in the Driver CD
Kit.
Dell Printer Configuration Web Tool Setting Items
You can configure the following setting items using Dell Printer Configuration Web Tool:
For information on how to start Dell Printer Configuration Web Tool, refer to "Starting Dell Printer
Configuration Web Tool" (P.464).
• Spool Destination for Jobs
([Properties] > [General Setup] > [Memory Settings] > [SMB])
• Port Settings
• Transport Protocol
• Maximum Connections
•Workgroup
• Server Name
• TBCP Filter
•Unicode
®
Support
• Auto Master Mode
•Password Encryption
• Obtain WINS Server Address Automatically
• Primary Server IP Address & Port
• Secondary Server IP Address & Port
