19 Scanner Environment Settings
504
Configuration of Job Flow Sheets
This section describes how to configure the machine to use the Job Flow Sheets service.
The following shows the reference section for each procedure.
Step 1 Enabling Ports and Setting up TCP/IP .......................................................................504
Step 2 Configuring the SNMP Port........................................................................................505
Step 3 Configuration on the Computer .................................................................................505
Step 1 Enabling Ports and Setting up TCP/IP
To use the Job Flow Sheets service, enable the SOAP, SNMP, and Internet Services (HTTP)
ports, and set an IP address and other addresses. The following describes the configuration
procedures on the machine.
Note • You can configure the settings using Dell Printer Configuration Web Tool. For information on how to
use Dell Printer Configuration Web Tool, refer to "Dell Printer Configuration Web Tool Settings" (P.461).
1 Display the [Tools] screen.
1) Press the <Log In/Out> button.
2) Enter the system administrator's user ID with the numeric keypad or the keyboard
displayed on the screen, and select [Enter].
When a passcode is required, select [Next] and enter the system administrator's passcode,
and select [Enter].
Note • The default user ID is "admin".
• The default passcode is "1111".
3) Select [Tools] on the [Home] screen.
2 Enable the SOAP port.
1) Select [Connectivity & Network Setup].
2) Select [Port Settings].
3) Select [SOAP], and then select [Change Settings].
4) Select [Port Status], and then select [Change Settings].
5) Select [Enabled], and then select [Save].
6) Select [Close] repeatedly until the [Port Settings] screen is displayed.
3 Enable the SNMP port.
1) Select [SNMP], and then select [Change Settings].
2) Select [Port Status], and select [Change Settings].
3) Select [Enabled], and then select [Save].
4) Select [Close] repeatedly until the [Port Settings] screen is displayed.
5) Enable the Internet Services (HTTP) port as described above.
6) Select [Close] repeatedly until the [Tools] screen is displayed.
4 Set an IP address and the other addresses.
Skip this step if an IP address is already set.
If DHCP or BOOTP is available in your environment, configure the method for obtaining
the addresses. If an IP address cannot be obtained automatically or manual configuration is
preferred, confirm the settings of an IP address, a subnet mask, and a gateway address.
