Connectivity & Network Setup
367
Domain Name
Enter the domain name with up to 64 single-byte characters.
Proxy Server Settings
Configure the settings for a proxy server.
Configure a proxy server when using inbound/outbound access.
Note • Do not set this item unless you use services requiring proxy server settings.
Use Proxy Server
Select whether or not to use a proxy server.
Proxy Server Setup
Select the proxy server specification from [Same Proxy for All Protocols] or [Different Proxy
for Each Protocol].
Addresses to Bypass Proxy Server
Enter addresses not using the proxy server. You can specify the addresses by IPv4 address,
IPv6 address, and FQDN. You can use wildcards "*" for specifying the addresses.
HTTP Proxy Server Name
Enter the server name or IP address of the HTTP proxy server. Up to 255 characters are
allowed. You can specify the addresses by IPv4 address, IPv6 address, and FQDN.
HTTP Proxy Server Port Number
Set the HTTP proxy server port number from 1 to 65535.
The default value is 8080.
Note • Do not use the numbers assigned to the other ports.
HTTP Proxy Server Authentication
Select [Enabled] when authentication is required to connect to the HTTP proxy server.
HTTP Proxy Server Login Name
Enter a login name of the HTTP proxy server. Up to 31 characters are allowed.
HTTP Proxy Server Password
Enter a password of the HTTP proxy server. Up to 31 characters are allowed.
HTTPS Proxy Server Name
Enter the HTTPS proxy server name or the IP address. Up to 255 characters are allowed. You
can specify the addresses by IPv4 address, IPv6 address, and FQDN.
HTTPS Proxy Server Port Number
Set the HTTPS proxy server port number from 1 to 65535.
The default value is 8080.
Note • Do not use the numbers assigned to the other ports.
HTTPS Proxy Server Authentication
Select [Enabled] when authentication is required to connect to the HTTPS proxy server.
