116
Operator Panel
3
Touch Panel
• Specifies the settings by directly tapping the screen.
• Displays various settings, instructions, and error messages.
4
Ready / Error LED
• Shows a green light when the printer is ready and a blinking green light when data is being received.
• Shows an amber light when an error occurs and a blinking amber light when an unrecoverable print error
occurs.
5
Number Pad
• Enters numbers and characters.
6
(Redial / Pause)
button
• Calls up the last called number.
• Inserts a pause into a telephone number.
7
(
Copy
) button
• Starts copying the document. Effective only from the
Home
screen while you are logged in to the printer.
8
(Power Saver)
button
• Enters or exits the Power Saver mode. When the printer is not used for a while, it enters the Power Saver mode
to reduce power consumption. When the Power Saver mode is active, the (Power Saver) button blinks.
9
(
NFC
) reader
• Starts communication between the printer and an NFC card or a mobile device with the NFC function when
the card or the device is tapped to the reader.
10
/(
Speed Dial 1
/
Speed Dial 2
) button
• Starts faxing the document to the number registered as "001" and "002" respectively of the FAX Speed Dial.
Effective only when the
Home
screen is displayed.
11
(Delete)
button
• Deletes numbers and characters.
12
(Job Status)
button
• Moves to the
Job Status
screen. From this screen, you can check or cancel active jobs.
13
(Information) Wi-Fi|WPS
button
• Moves to the
Information
screen. You can access various information and settings menu including Wi-Fi and
Wi-Fi Direct features, check the name of the connected device via Wi-Fi Direct, check consumable levels and
network status, and print various types of reports and lists.
14
(Information)
button
• Moves to the
Information
screen. You can access various information and settings menu, check consumable
levels and network status, and print various types of reports and lists.
NOTE:
Moving to a different menu or returning to a previous screen cancels the current entry or setting. Be sure to select
OK
to
save the current entry or setting.
To Next Page
