Clearing Jams
473
f
Close the DADF cover, and then load the documents back into the DADF.
NOTE:
Ensure that you adjust the document guides before printing a Legal-size document.
2
If you cannot see the jammed document or the jammed document do not move when you pulled, open the
document cover.
3
Remove the document from the white sheet by carefully pulling it to the right.
4
Close the document cover, and then load the documents back into the DADF.
5
Ta p
Start
.
If status code: 005-110 appears:
1
Remove the jammed and the remaining documents from the DADF.
You do not have to open the DADF cover.
2
Load the documents back into the DADF.
3
Ta p
Start
.
Clearing Paper Jams From the MPF
NOTE:
To resolve the error displayed on the touch panel, you must clear all print media from the print media path.
1
Remove any paper loaded on the MPF
To Next Page
