Dell S2815dn - Identifying the Location of Paper Jams

470 Clearing Jams
Identifying the Location of Paper Jams
WARNING: Do not attempt to clear any jams using tools or instruments. This may permanently damage the printer.
The following illustration shows where paper jams may occur along the print media path.
1 Duplex Automatic Document Feeder (DADF)
2 Fusing Unit
3 Regi Roll
4 Duplexer
5 Tr ay 1
6 Optional 550-Sheet Feeder
7 Multipurpose Feeder (MPF)
7
65
4
3
1
2
