Understanding the Printer Menus
195
WPS Setup
Purpose:
To configure the wireless network using WPS.
Va lu e s:
Infrastructure Select when you configure the wireless settings through the
access point such as a wireless router.
No Security
*
Specifies No Security to configure the wireless settings
without specifying an encryption type.
Mixed mode PSK Select to configure the wireless settings with the encryption
type of Mixed mode PSK. Mixed mode PSK automatically
selects the encryption type from either WPA-PSK-TKIP,
WPA-PSK-AES, or WPA2-PSK-AES.
Passphrase Specifies the passphrase of
alphanumeric characters from 8 to 63.
WPA2-PSK-AES Select to configure the wireless settings with the encryption
type of WPA2-PSK-AES.
Passphrase Specifies the passphrase of
alphanumeric characters from 8 to 63.
(hex: 0-9, a-f, A-F, 16 to 64 characters)
WEP Specifies the WEP key to use through the wireless network.
For 64bit keys, 10 hexadecimal characters can be entered.
For 128bit keys, 26 hexadecimal characters can be entered.
Transmit Key Specifies the transmit key from Auto
*
,
WEP Key 1, WEP Key 2, WEP Key 3,
and WEP Key 4.
Ad-hoc Select to configure the wireless settings without the access
point such as a wireless router.
No Security
*
Select to configure the wireless settings without specifying
the encryption type from WEP.
WEP Specifies the WEP key to use through the wireless network.
For 64bit keys, up to 10 hexadecimal characters can be
entered. For 128bit keys, up to 26 hexadecimal characters
can be entered.
Transmit Key Specifies the transmit key from WEP
Key 1
*
, WEP Key 2, WEP Key 3, and
WEP Key 4.
Push Button
Configuration
*
Start Configuration Configures the wireless settings with WPS-PBC.
PIN Code Start Configuration Configures the wireless settings using the PIN code assigned automatically
by the printer.
Print PIN Code Prints the PIN code. Confirm it when entering PIN assigned to the printer
into your computer.
