Dell S2815dn User Manual

Installing Printer Drivers on Windows
®
Computers 93
4 Select the printer you want to install from the printer list, and then click Next . If the target printer is not displayed
on the list, click the (Refresh) button to refresh the list or click
add printer manually to add a printer to the list
manually. You may specify the IP address and port name at this point.
If you have installed this printer on the server computer, select the
I am setting up this printer on a server check
box.
NOTE: When using AutoIP, 0.0.0.0 is displayed in the installer. Before you can continue, you must enter a valid IP
address.
NOTE: If Windows Security Alert is displayed in this step, select Unblock or Allow access, and then continue the
procedure.
5 Specify the printer settings, and then click Next .
a Enter the printer name.
b If you want to set the printer as the default printer, select the Set this printer as default check box.
c If you want to install the PostScript 3 Compatible printer driver, select the PS Driver check box.
If you want to install the Fax Driver, select the
Fax Driver check box.
d If you want other users on the network to access the printer, select Share this printer with other computers on
the network
, and then enter a share name that users can identify.
6 Select the software and documentation you want to install, and then click Install . If you want to change the
installation destination, click
Change Destination Folder and specify a new location.
7 Click Finish to exit the wizard when the Ready to Print! screen appears.
If you want to verify installation, click
Print Test Page before clicking Finish .
For installing XML Paper Specification (XPS) printer driver
NOTE: XML Paper Specification (XPS) driver is supported on Windows Vista
®
or later.
Windows Vista
®
or Windows Vista
®
64-bit Edition
1
Extract the following zip file to your desired location.
D:\Drivers\XPS\Win_7Vista\XPS-V3_H815dw_S2815dn.zip (where D is the drive letter of the
optical drive)
2 Click Start  Control Panel  Hardware and Sound  Printers .
3 Click Add a printer .
4 Click Add a network , wireless or Bluetooth printer .
5 Select printer and click Next , or click The printer that I want isn't listed .
6 Select Add a printer using a TCP/IP address or host name , and then click Next .
7 Select TCP/IP Device from Device type , and enter the IP address for Hostname or IP address , and then click
Next .
If the
User Account Control dialog box appears, click Continue .
NOTE: If you are an administrator on the computer, click Continue; otherwise, contact your administrator to continue the
desired action.
8 Click Have Disk to display the Install From Disk dialog box.
9 Click Browse , and then select the inf file in the folder extracted in step 1.
10 Click OK .
11 Select your printer name and click Next .

Dell S2815dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Maximum copy resolution	- DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 297 mm
Output color depth	24 bit
Scan speed (color)	17 ppm
Image formats supported	JPEG XR
Maximum scan resolution	9600 x 9600 DPI
Document formats supported	PDF
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	80000 pages per month
Recommended duty cycle	700 - 4000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3
Cabling technology	10/100/1000Base-T(X)
Authentication method	HTTP, HTTPS, TLS 1.2, SNMP (v1 / v2 / v3), MIBv2, BOOTP, DHCP, RARP, Auto IP, WINS, DNS, Bonjour (mDNS), Telnet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print
Supported network protocols (IPv4)	IPSEC w/ IPv4
Supported network protocols (IPv6)	IPSEC w/ IPv6
Internal memory	1024 MB
Card reader integrated	No
Sound pressure level (printing)	52.9 dB
Control type	Touch
Product color	Black
Display diagonal	4.3 \
Market positioning	Business
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	900 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Operating altitude	0 - 3100 m
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	15 - 85 %
Certification	EN 60950-1/IEC 60950-1; EN 55022 (Class B) EN55024 EN61000-3-2 (Class A) EN 61000-3-3 CE Mark (EU) UL 60950-1 / CAN/CSA-C22.2 No. 60950-1-07; ICES-003 (Canada) US CFR Title 47 FCC Part 2 and 15B Part 15C and Part 68 FDA/DHHS (21CFR Chapter 1 Subchapter J RCM (Australia) Telepermit (New Zealand) Singapore Mark SABS/ICASA (South Africa) NOM NYCE (Mexico) GS Mark (Germany) and other certifications required by individual country. WHQL Citrix SAP Novell YES USB Google Cloud Print Mopria AirPrint
Sustainability certificates	Blue Angel, RoHS, ENERGY STAR
AC input voltage	110 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (sleep)	14 W
Power consumption (standby)	52 W
Power consumption (average operating)	610 W

Weight and Dimensions

Depth	556 mm
Width	557 mm
Height	644 mm
