Chapter 5 Parameters|VFD-M-D Series
5-56 Revision Jan. 2007, MDE2, SW V1.05
Settings Function Description
16 External Reset (N.C.)
key on the digital keypad. After faults such as O.H.,
O.C. and O.V. are cleared, this input can be used to
reset the drive.
17
The signal when it is in open
completed position
When Pr.0-15 is set to 01 or 03, drive will open the door
to the completed position by this signal.
18
The signal when it is in close
completed position
When Pr.0-15 is set to 02 or 03, drive will close the door
to the completed position by this signal.
19 Open Allowance Signal
When this setting is enabled, it allows to open the door.
It also can be used for the signal of door zone.
20 Force Door open Signal
When this setting is enabled, it will force opening the
door. Only when this setting is disabled, the door can be
closed. This signal will be invalid when the door is in the
close complete position.
When value 19 is set, this setting can be ON after the
value 19 is ON.
21 Home Return
When this setting is enabled, the drive will execute
position function.
22
The curve selection for
1st/2nd step door open/close
When this setting is ON, it will run the curve of 2
nd
step
door open/close.
23
The signal when it is in open
completed position, including
RUN signal
When Pr.0-15 is set to 01 or 03, it will open the door to
the completed position by this signal. This signal also
can run the drive when there is no RUN command and
operation direction is REV. It can be used for holding
torque when the open command is disabled after door
is in the open complete position.
24
The signal when it is in close
completed position, including
RUN signal
When Pr.0-15 is set to 02 or 03, it will close the door to
the completed position by this signal. This signal also
can run the drive when there is no RUN command and
operation direction is FWD. It can be used for holding
torque when the close command is disabled after door
is in the close complete position.
 N.O.= Normally Open. N.C.= Normally Closed.
5 - 11 Line Start Lockout (only for external terminals)
Factory Setting: 00
Settings 00 Disable
01 Enable
 When the operation command source is from external terminal and operation command is ON
(FWD/REV-DCM=close), the AC motor drive will operate according to Pr.5-11 after power is
applied. <For terminals FWD and REV only>
