Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-63
Settings Function Description
03 Over-Torque Detection
Active as long as over-torque is detected. (Refer to Pr.7-06 ~
Pr.7-07)
04 Low-Voltage Indication
Active when low voltage(Lv) is detected.
05
Operation Mode
Indication
Active when operation command is controlled by external
terminal.
06 Fault Indication
Active when faults occur (oc, ov, oH1, oL2, oL, oL1, EF,
CF3.3~8, HPF1~4, ocA, ocd, ocn, GFF, PGEr, doEr, CE10).
07 Warning Indication
Active when warnings occur (AUE, SE1, SE2, oL2, PGEr,
PSEr, CE0X)
08 Demo indication
Active when demo is executed.
09 A step completed
Active when a step is completed for only 0.5 seconds.
10 A demo completed
Active when a demo is completed for only 0.5 seconds.
11 Forced Stop Indication
Active when the action of forced stop occur.
12
Heat Sink Overheat
Warning (OH)
When heatsink overheats, it will signal to prevent OH turn off
the drive. When it is higher than 85
o
C (185
o
F), it will be ON.
Or it will be OFF.
13 AC Motor Drive Ready
Active when the drive is ON and no abnormality detected or
AC motor drive is in the state that waits for press “RESET” to
clear the fault.
14
Emergency Stop
Indication
Active once the drive’s emergency stop function is activated.
15 Software Braking Signal
This function is used in conjunction with a VFDB Braking
Unit. The output will be activated when the drive needs help
braking the load. A smooth deceleration is achieved by using
this function.
16
Zero Speed Output
Signal
Active unless there is an output frequency present at
terminals U/T1, V/T2, and W/T3.
17 Feedback Signal Error
Active when the feedback signal is abnormal. (Refer to Pr.2-
18, Pr.2-19)
18 Position Detection 1
Active when the door close to the position that is equal to
Pr.6-09.
19 Position Detection 2
Active when the door close to the position that is equal to
Pr.6-10.
20 Position Detection 3
Active when the door close to the position that is equal to
Pr.6-11.
