Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-65
Weights
Bit
22222222
01100100
The setting value
bit7x2+bit6x2+bit5x2+bit4x2+bit3x2+bit2x2+bit1x2+bit0x2
0x2+1x2+1x2+0x2+0x2+1x2+0x2+0x2
0+64+32+0+0+4+0+0
100
＝
＝
＝
＝
setting 6-08 100 ＝
7
7
76543210
Relay 1 =N.O
Relay 2 =N.O
MO1 =N.C
MO2 =N.O
MO3 =N.O
MO4 =N.C
MO5 =N.C
MO6 =N.O
*0 N.O *1 N.C ＝＝
6
5
43 210
6
5
43 210
NOTE:
2 1 2 8 2 64
2 2 2 16 2 128
2 4 2 32
＝＝＝
＝＝＝
＝＝
0
1
2
3
4
5
6
7
 When Pr.6-00 to Pr.6-07 is set to 18 to 20, it will output a signal once the door is in the position
that Pr.6-09 to Pr.6-11 set.
6 - 09
Position Detection 1
Unit: 0.1
Settings
0.0 to 100.0%
Factory Setting: 25.0
6 - 10
Position Detection 2
Unit: 0.1
Settings
0.0 to 100.0%
Factory Setting: 12.5
6 - 11
Position Detection 3
Unit: 0.1
Settings
0.0 to 100.0%
Factory Setting: 7.5
6 - 12
Reserved
6 - 13
Reserved
6 - 14
Reserved
6 - 15
Reserved
