134
10
SURROUND
Adjustment steps that need to be performed prior to surround sound playback
If the Auto Setup procedure has not been performed or the channel level has not been adjusted at the System Setup Menu, the settings below
cannot be made.
1
Press the TEST TONE button.
2
Test tones are output from the different speakers.
Use the Cursor left and right button to adjust the
channel level so that the volume of the test tones is
the same for all the speakers.
3
After completing the adjustment, press the TEST
TONE button again.
(Remote control unit)
(Remote control unit)
(Remote control unit)
[2] Channel Level
• After adjusting using the test tones, adjust the channel levels either according to the playback sources or to suit your tastes, as described
below.
1
Press the ENTER button on the Main unit or Remote
control unit. The screen below appears.
(Main unit)
(Remote control unit)
¥¥¥¥¥¥ńţŜũũŠŧ¥ŗŪŧ©
¥
Ňō¥¥¥¥¥ĸ©ĸ
şŃ¥
Ŕœ¥ł¥¥¥ĸ©ĸ
şŃ
ń¥¥¥¥¥¥ĸ©ĸ
şŃ¥
Ŕœ¥Ń¥¥¥ĸ©ĸ
şŃ
Ňœ¥¥¥¥¥ĸ©ĸ
şŃ¥
ŔŃœ¥¥¥¥ĸ©ĸ
şŃ
ŔŘ¥¥¥¥¥ĸ©ĸ
şŃ¥
ŔŃō¥¥¥¥ĸ©ĸ
şŃ
¥¥¥¥¥¥¥¥¥¥¥¥Ŕō¥Ń¥¥¥ĸ©ĸ
şŃ
¥¥¥¥¥¥¥¥¥¥¥¥Ŕō¥ł¥¥¥ĸ©ĸ
şŃ
¥¥¥¥¥¥¥¥¥¥¥¥ŇŜşŠŭ
¥¥¥¥¥¥¥¥¥¥¥¥ŇœŐŏŕ¥«¥œņłœ
Channels which is not used are not displayed.
2
Select the speaker level you want to adjust.
• When pressing the ENTER button, the channel switches as shown below
each time the ENTER button is pressed.
(Remote control unit)
[1] Test Tone
• Before playing with the surround function, be sure to use the test tones to adjust the playback level from the different speakers. This
adjustment can be performed with the system setup (pages 51, 52) or from the Remote control unit, as described below.
• Adjusting with the Remote control unit using the test tones is only possible in the “Auto” mode and only effective in the STANDARD
(DOLBY/DTS SURROUND) modes. The adjusted levels for the different modes are automatically stored in the memory.
(Main unit)
FADER
SRA
SBL
SLB
SLA
SRB
SBR
FL
C
FR
SW
or or
