10. Service Mode Field Service Ver. 1.0 Apr. 2005
106
ineo 161
ineo 210
Adjustment / Setting
E. Latin America (Metric)
F. Latin America (Inch)
G. OEM1 US
10.3.8 FACTORY TEST
A. PANEL BUZZER TEST
B. RAM TEST
Setting name Default fixed zoom ratio Setting range
REDUCTION2 70% 51% to 70%
REDUCTION1 78% 71% to 99%
EXPANSION1 115% 101% to 140%
EXPANSION2 141% 141% to 199%
Setting name Default fixed zoom ratio Setting range
REDUCTION2 64% 51% to 64%
REDUCTION1 78% 65% to 99%
EXPANSION1 121% 101% to 128%
EXPANSION2 129% 129% to 199%
Setting name Default fixed zoom ratio Setting range
REDUCTION2 64% 51% to 64%
REDUCTION1 77% 65% to 99%
EXPANSION1 129% 101% to 154%
EXPANSION2 155% 155% to 199%
Purpose/Use To test LEDs and keys on control panel
Setting/
Procedure
PANEL LED TEST
• Make sure that all LEDs on control panel light (for 5 seconds).
PANEL SWITCH TEST
• Press the control keys and numeric keys, and make sure that the names of switches
appear in the LCD display.
✽ To release the test, press the panel reset key twice: The initial screen will be
restored.
Purpose/Use Write or read data to/from RAM memory to make sure of normal operation.
Setting/
Procedure
1. Pressing the YES key will start the check.
2. After approx. 30 seconds, “RAM Chip is OK” will appear.
To Next Page
