Field Service Ver. 1.0 Apr. 2005 14. Jam Display
127
ineo 161
ineo 210
Troubleshooting
14.3.8 Misfeed at the Document Take-up Section
(When the optional Automatic Document Feeder DF-502 is mounted)
A. Detection Timing
B. Action
Type Description
Document take-up
section misfeed
detection
• The Separator Sensor (PC4/AF) is not blocked even after the lapse of a given
period of time after the Main Motor (M1/AF) has been energized.
Document left in
the document
take-up section
• The Separator Sensor (PC4/AF) is blocked at timing when the Power Switch is
turned ON, the cover is opened and closed, or a paper misfeed or malfunction
is reset.
Relevant Electrical Components
Main Motor (M1/AF)
Separator Sensor (PC4/AF)
Interface Board (PWB/AF)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1 Initial checks – – –
2 M1/AF operation check
☞ 117 –
3 PC4/AF sensor check
☞ 115 PWB/AF CN2/AF-9 (ON)
4 Replace PWB/AF – – –
To Next Page
