Field Service Ver. 1.0 Apr. 2005 15. Malfunction code
141
ineo 161 ineo 210
Troubleshooting
15.3.7 C0500: Warm-up Failure
15.3.8 C0501: Warm-up Failure 2 (ineo 210 Only)
15.3.9 C0510: Fusing Failure (Abnormally Low Fusing Temperature)
15.3.10 C0511: Fusing Failure (Abnormally Low Fusing Temperature 2)
(ineo 210 Only)
15.3.11 C0520: Fusing Failure (Abnormally High Fusing Temperature)
15.3.12 C0521: Fusing Failure (Abnormally High Fusing Temperature 2)
(ineo 210 Only)
A. Detection Timing
Trouble Code Description
C0500
• The surface temperature of the Fusing Roller does not reach a given level even
after the lapse of a given period of time during a warm-up cycle.
From room temperature to 100°C : 35 sec.
From 100°C to 140°C : 25 sec.
From 140°C to the completion of the warm-up cycle : 20 sec.
C0500
• The Fusing Roller Thermistor does not detect a predetermined temperature
within 30 sec. after a warm-up cycle has been started and thus the warm-up
cycle is not completed.
• The surface temperature of the Fusing Roller does not reach a given level even
after the lapse of a given period of time during a warm-up cycle.
From room temperature to 60°C : 4 sec.
From 60°C to 100°C : 2 sec.
From 100°C to 130°C : 1 sec.
From 130°C to 155°C : 0.5 sec.
C0501
• The Fusing Roller Sub Thermistor does not detect a predetermined tempera-
ture within 30 sec. after a warm-up cycle has been started and thus the warm-
up cycle is not completed.
• The surface temperature of the Fusing Roller does not reach a given level even
after the lapse of a given period of time during a warm-up cycle.
From room temperature to 60°C : 7 sec.
From 60°C to 100°C : 2 sec.
From 100°C to 130°C : 1 sec.
From 130°C to 155°C : 0.5 sec.
C0510
• The surface temperature of the Fusing Roller remains lower than 120°C (105°C
for the model having two Fusing Roller Heater Lamps) for a given period of time
during the standby state.
• The surface temperature of the Fusing Roller remains lower than 120°C (105°C
for the model having two Fusing Roller Heater Lamps) for a given period of time
during a print cycle.
C0511
• The temperature detected by the Fusing Roller Sub Thermistor remains lower
than 105°C for a given period of time during the standby state.
• The temperature detected by the Fusing Roller Sub Thermistor remains lower
than 105°C for a given period of time during a print cycle.
C0520
• The temperature detected by the Fusing Roller Thermistor remains higher than
240°C for a given period of time.
C0521
• The temperature detected by the Fusing Roller Sub Thermistor remains higher
than 240°C for a given period of time.
