14.3.4 Misfeed at the Multiple Bypass Paper Take-up Section
(When the optional Multiple Bypass MB-501 is mounted)
A. Detection Timing
B. Action
Type Description
Paper take-up
section misfeed
detection
• The leading edge of the paper does not unblock the Synchronizing Roller Sen-
sor (PC1) even after the lapse of a given period of time after the Paper Take-up
Solenoid (SL21/MB) has been energized.
Size error detection
• The Synchronizing Roller Sensor (PC1) is not blocked even after the lapse of a
given period of time after the paper has unblocked the Synchronizing Roller
Sensor (PC1).
• The Synchronizing Roller Sensor (PC1) is blocked before the lapse of a given
period of time.
Relevant Electrical Components
Synchronizing Roller Sensor (PC1)
Paper Take-up Solenoid (SL21/MB)
Master Board (PWB-A)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1 Initial checks – – –
2 PC1 sensor check
☞ 115 PWB-A PJ17A-3 (ON)
3 SL21/MB operation check
☞ 116 PWB-A PJ12A-2 (REM)
4 Replace PWB-A – – –
