Develop ineo 161 - Cleaning Parts List

6. Other Field Service Ver. 1.0 Apr. 2005
30
ineo 161 ineo 210
Maintenance
6.2.2 Cleaning parts list
34
Others
Main Motor ☞ 54
35 Power Unit Cooling Fan Motor
☞ 55
36 Fusing Cooling Fan Motor
☞ 55
37 Paper Size Sensor Assy
☞ 56
38 Fusing Unit Interlock Switch
☞ 57
39 Inch/Metric Sensor/1 Assy
☞ 59
40 Flickerless Resistor
☞ 59
41 Separation Roller
☞ 60
42 Feed Roller
☞ 60
43 Upper/Lower Synchronizing Rollers
☞ 60
44 Paper Dust Remover
☞ 61
45 Bypass Transport Roller/Roll
☞ 61
No. Section Part name Ref.Page
No. Section Part name Ref.Page
1
IU
PC Drum Paper Separator Fingers
☞ 15
2 Ds Collars
☞ 15
3 Developer Scattering Prevention Plate
☞ 15
4 Pre-Image Transfer Guide Plate
☞ 16
5
IR
Mirrors
☞ 62
6Lens
☞ 62
7 CCD Sensor
☞ 62
8 Scanner Rails/Bearings
☞ 63
9 PH PH Window
☞ 63
10
Image transfer section
Pre-Image Transfer Lower Guide Plate
☞ 63
11 Charge Neutralizing Plate
☞ 64
